RESS-P20-L0 (US)

Hybrid inverter for residential energy storage system (Low voltage)

























Hybrid Power Leverage

Support PV, grid and battery power for home use. Power priority management to maximum reduce electricity bill and backup critical load.

High-Level Integration

DC coupled system. Shorten power conversion flow to get low power loss.

High Compatible With Self- Design Battery Energy Storage Systems

Deep communicate and coordinate between inverter and battery, enhance the system reliability considerably.

Multi-Communication Capabilities

Supports RS485, CAN2.0, WIFI, and 4G communication.

Concise Human-Machine Interface

Easy operated local LCD display and app. Quick status indicators.

Safe Design

Multiple protection and detection function provide full safety guarantee.





Hybrid Inverter Model RESS-3P-6K-L00-LV RESS-3P-10K-L00-LV
Output (On Grid)
Rated Output Active Power  6000W 10000W
Max. Output Apparent Power  6000VA 10000VA
Rated AC Voltage 120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
AC Voltage Range 105.5 VAC - 132 VAC (P-N)
AC Frequency Range 50 / 60Hz±5Hz
Wiring L1/L2-N-G
Max. Output Current 25A 41.5A
Max. Input Current 40A
Power Factor (cosΦ) 0.9 leading – 0.9 lagging
THDI <3%
Output (Back up)
Rated Output Apparent Power  6000VA 10000VA
Rated Output Active Power  6000W 10000W
Rated Output Voltage 120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
Rated Output Frequency 50/60Hz
Max. Output Current 25A 41.5A
THDV(@Linear Load) <3%
Switch Time <15ms
PV String Input
Recommended Max. PV Input Power 7500W 12000W
Rated DC Voltage 360V
Operating Voltage Range 120V-550V
Startup Voltage 125V
MPPT Voltage Range 120V-550V
Number of MPPTs 2
Max. Number of PV Strings per MPPT 2
Max. Input Current per MPPT  15A 18A
Battery
Battery Type LFP (LiFePO4)
Rated Battery Voltage 48V
Battery Voltage Range 40-62V
Max. Charging Current 120A 200A
Max. Discharging Current 150A 300A
Efficiency
Max. PV Efficiency 96.5%
Euro. PV Efficiency 95.5%
Protection
PV Over Voltage Protection Yes
String Fault Detection Yes
Residual Current Detection Yes
Insulation Detection Yes
Anti-Islanding Protection Yes
DC Switch (battery) Yes
DC Reverse Polarity Protection (Both PV and Battery) Yes
AC/DC Surge Protection DC Type II;AC Type III
AC Over Voltage Protection Yes
AC Over Current Protection Yes
AC Short Circuit Protection Yes
Leakage Current Detection Yes
Ground Connection Detection Yes
Function
Battery Charging From Grid Yes
General
Dimensions W*H*D 515*700*215.5mm 515*715*215.5mm
Net Weight 41kg 45kg
Installation Wall-mounted
Operating Temperature Range -25℃~+60℃, (derating above 45℃)
Storage Temperature Range -15℃~60℃
Max. Operating Altitude  1000m (no derating, over 1000m the power derating is 1 % every 100m)
Relative Humidity Range 0~95% (No Condensation)
Ingress Protection Rating IP65
Cooling Force air cooling
Noise <50dB
Communication RS 485, RS232, USB, Dry contact, WIFI
Display LCD/APP
Warranty 2 years
Certification UL1741, IEEE1547, EN 61000-6-2,EN 61000-6-4
Compatible Battery System
Compatible Battery System RESS-BS-6.6-L0; RESS-BS-13.2-L0; RESS-BS-19.8-L0



Product Description

Hybrid Power Leverage

Support PV, grid and battery power for home use. Power priority management to maximum reduce electricity bill and backup critical load.

High-Level Integration

DC coupled system. Shorten power conversion flow to get low power loss.

High Compatible With Self- Design Battery Energy Storage Systems

Deep communicate and coordinate between inverter and battery, enhance the system reliability considerably.

Multi-Communication Capabilities

Supports RS485, CAN2.0, WIFI, and 4G communication.

Concise Human-Machine Interface

Easy operated local LCD display and app. Quick status indicators.

Safe Design

Multiple protection and detection function provide full safety guarantee.

Product Pairing



Product Specification



Hybrid Inverter Model RESS-3P-6K-L00-LV RESS-3P-10K-L00-LV
Output (On Grid)
Rated Output Active Power  6000W 10000W
Max. Output Apparent Power  6000VA 10000VA
Rated AC Voltage 120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
AC Voltage Range 105.5 VAC - 132 VAC (P-N)
AC Frequency Range 50 / 60Hz±5Hz
Wiring L1/L2-N-G
Max. Output Current 25A 41.5A
Max. Input Current 40A
Power Factor (cosΦ) 0.9 leading – 0.9 lagging
THDI <3%
Output (Back up)
Rated Output Apparent Power  6000VA 10000VA
Rated Output Active Power  6000W 10000W
Rated Output Voltage 120 VAC (P-N), 208 VAC (P-P), 240 VAC (P-P)
Rated Output Frequency 50/60Hz
Max. Output Current 25A 41.5A
THDV(@Linear Load) <3%
Switch Time <15ms
PV String Input
Recommended Max. PV Input Power 7500W 12000W
Rated DC Voltage 360V
Operating Voltage Range 120V-550V
Startup Voltage 125V
MPPT Voltage Range 120V-550V
Number of MPPTs 2
Max. Number of PV Strings per MPPT 2
Max. Input Current per MPPT  15A 18A
Battery
Battery Type LFP (LiFePO4)
Rated Battery Voltage 48V
Battery Voltage Range 40-62V
Max. Charging Current 120A 200A
Max. Discharging Current 150A 300A
Efficiency
Max. PV Efficiency 96.5%
Euro. PV Efficiency 95.5%
Protection
PV Over Voltage Protection Yes
String Fault Detection Yes
Residual Current Detection Yes
Insulation Detection Yes
Anti-Islanding Protection Yes
DC Switch (battery) Yes
DC Reverse Polarity Protection (Both PV and Battery) Yes
AC/DC Surge Protection DC Type II;AC Type III
AC Over Voltage Protection Yes
AC Over Current Protection Yes
AC Short Circuit Protection Yes
Leakage Current Detection Yes
Ground Connection Detection Yes
Function
Battery Charging From Grid Yes
General
Dimensions W*H*D 515*700*215.5mm 515*715*215.5mm
Net Weight 41kg 45kg
Installation Wall-mounted
Operating Temperature Range -25℃~+60℃, (derating above 45℃)
Storage Temperature Range -15℃~60℃
Max. Operating Altitude  1000m (no derating, over 1000m the power derating is 1 % every 100m)
Relative Humidity Range 0~95% (No Condensation)
Ingress Protection Rating IP65
Cooling Force air cooling
Noise <50dB
Communication RS 485, RS232, USB, Dry contact, WIFI
Display LCD/APP
Warranty 2 years
Certification UL1741, IEEE1547, EN 61000-6-2,EN 61000-6-4
Compatible Battery System
Compatible Battery System RESS-BS-6.6-L0; RESS-BS-13.2-L0; RESS-BS-19.8-L0
