ACE Battery

Aerial Work Platform Battery Wholesale | ACE Battery

Experience reliable and efficient motive power solutions with ACE Battery. Our high-performance motive power batteries are designed to deliver exceptional power and longevity, making them the ideal choice for various applications. Trust the leading manufacturer for all your motive power battery needs.

Motive Power Manufacturer | ACE Battery

<div class='sa_b_component_richtext_unique'>
  <style>
       .sa_b_component_richtext_unique p {
            margin: 0;
        }
       .sa_b_component_richtext_unique img {
            max-width: 100%;
            margin-bottom: 20px;
        }
       .sa_b_component_richtext_unique table {
            max-width: 100%;
            min-height: 80px;
            margin-bottom: 20px;
            overflow: auto;
        }
       .sa_b_component_richtext_unique td {
            padding: 12px;
        }
       .sa_b_component_richtext_unique ul {
            margin-left: 20px;
        }
       .sa_b_component_richtext_unique ol {
            margin-left: 20px;
        }
       .sa_b_component_richtext_unique li::marker {
            font-size: 16px;
        }
    </style>
    <p>ACE's LiFePO4 battery systems for scissor lifts (AWP) are maintenance-free, fast charging, longer life and environmentally friendly, making working at heights safer, more efficient, and more economical. More stable, lighter, and more environmentally friendly than lead acid, the battery has good waterproof performance, higher energy density and excellent compatibility.</p>
<h3 style="line-height: 2; text-align: center;">&nbsp;</h3>
<h3 style="line-height: 2; text-align: center;"><strong>Features</strong></h3>
<p>&nbsp;</p>
<table style="border-collapse: collapse; width: 100%;" border="0">
<tbody>
<tr>
<td style="width: 33.3333%;">
<p><strong>Higher Performance</strong></p>
<p>LFP automotive-level battery cell adapted to meet 1.5C high-power discharge; deep discharge with efficiency up to 99%.</p>
</td>
<td style="width: 33.3333%;">
<p><strong>More Cost-effective</strong></p>
<p>Fast charging to ensure uninterrupted work, with up to 5000+ life cycles to save 70% of the cost compared with lead-acid.</p>
</td>
<td style="width: 33.3333%;">
<p><strong>Modular Expansion</strong></p>
<p>Standard battery pack design for capacity expansion in parallel; to make the most efficient use of battery compartment space.</p>
</td>
</tr>
<tr>
<td style="width: 33.3333%;">
<p><strong>More Safe</strong></p>
<p>A complete solution equipped with a dedicated charger, and intelligent BMS; IP65 water- and dust-proof.</p>
</td>
<td style="width: 33.3333%;">
<p><strong>Smaller &amp; Lighter</strong></p>
<p>Reduced 2/3 in size for portability with energy density 3 times greater than a lead-acid battery.</p>
</td>
<td style="width: 33.3333%;"><strong>&nbsp;</strong></td>
</tr>
</tbody>
</table>
</div>

<div class='sa_b_component_richtext_unique'>
  <style>
       .sa_b_component_richtext_unique p {
            margin: 0;
        }
       .sa_b_component_richtext_unique img {
            max-width: 100%;
            margin-bottom: 20px;
        }
       .sa_b_component_richtext_unique table {
            max-width: 100%;
            min-height: 80px;
            margin-bottom: 20px;
            overflow: auto;
        }
       .sa_b_component_richtext_unique td {
            padding: 12px;
        }
       .sa_b_component_richtext_unique ul {
            margin-left: 20px;
        }
       .sa_b_component_richtext_unique ol {
            margin-left: 20px;
        }
       .sa_b_component_richtext_unique li::marker {
            font-size: 16px;
        }
    </style>
    <div data-richtextkey9="">
<div data-richtextkey_def="">
<p>&nbsp;</p>
<div class="over-tabs">
<table style="border-collapse: collapse; border-color: #000000; border-style: solid;" border="1" cellspacing="0" cellpadding="0">
<tbody>
<tr class="firstRow" style="background-color: #005dbc;">
<td height="40"><span style="color: #ffffff;"><strong>Model</strong></span></td>
<td><span style="color: #ffffff;"><strong>FCM-2450</strong></span></td>
<td><span style="color: #ffffff;"><strong>FCM-24100</strong></span></td>
<td><span style="color: #ffffff;"><strong>FCM-24150</strong></span></td>
<td><span style="color: #ffffff;"><strong>FCM-24200</strong></span></td>
</tr>
<tr>
<td height="27">System / Nominal Voltage</td>
<td>24V / 25.6V</td>
<td>24V / 25.6V</td>
<td>24V / 25.6V</td>
<td>24V / 25.6V</td>
</tr>
<tr>
<td height="27">Available Capacity</td>
<td>50 Ah (1280 Wh)</td>
<td>100 Ah (2560 Wh)</td>
<td>150 Ah (3840 Wh)</td>
<td>200 Ah (5120Wh)</td>
</tr>
<tr>
<td height="27">Charge Voltage (V)</td>
<td>28.8</td>
<td>28.8</td>
<td>28.8</td>
<td>28.8</td>
</tr>
<tr>
<td height="27">EOD Voltage (V)</td>
<td>18.4</td>
<td>18.4</td>
<td>18.4</td>
<td>18.4</td>
</tr>
<tr>
<td height="27">Recommended Charge Current (A)</td>
<td>20</td>
<td>40</td>
<td>60</td>
<td>80</td>
</tr>
<tr>
<td height="27">Max. Charge Current (A)</td>
<td>50</td>
<td>80</td>
<td>100</td>
<td>120</td>
</tr>
<tr>
<td height="27">Continuous Discharge current (A)</td>
<td>60</td>
<td>120</td>
<td>180</td>
<td>240</td>
</tr>
<tr>
<td height="53">Dimensions (L*W*H)</td>
<td>12 * 6.5 * 7.3 inch<br />（304*164*185 mm）</td>
<td>12 * 6.5 * 7.3 inch *2 parallel<br />（304*164*185 mm) *2 parallel</td>
<td>12 * 6.5 * 7.3 inch *3 parallel<br />（304*164*185 mm) *3 parallel</td>
<td>12 * 6.5 * 7.3 inch * 4 parallel<br />（304*164*185 mm) *4 parallel</td>
</tr>
<tr>
<td height="27">Weight</td>
<td>25.4 Ibs （11.5 kg）</td>
<td>50.8 Ibs （23.0 kg）</td>
<td>76.2 Ibs （34.5 kg）</td>
<td>101.6 Ibs （46.0 kg）</td>
</tr>
</tbody>
</table>
</div>
<p>&nbsp;</p>
<div class="over-tabs">
<table style="border-collapse: collapse; border-color: #000000; border-style: solid;" border="1" cellspacing="0" cellpadding="0"><colgroup><col /><col /><col span="3" /></colgroup>
<tbody>
<tr class="firstRow" style="background-color: #005dbc;">
<td height="40"><strong><span style="color: #ffffff;">Model</span></strong></td>
<td><strong><span style="color: #ffffff;">FCM-3650</span></strong></td>
<td><strong><span style="color: #ffffff;">FCM-36100</span></strong></td>
<td><strong><span style="color: #ffffff;">FCM-36150</span></strong></td>
<td><strong><span style="color: #ffffff;">FCM-36320</span></strong></td>
</tr>
<tr>
<td height="27">System / Nominal Voltage</td>
<td>36V / 38.4V</td>
<td>36V / 38.4V</td>
<td>36V / 38.4V</td>
<td>36V / 38.4V</td>
</tr>
<tr>
<td height="27">Available Capacity</td>
<td>50 Ah (1.92 kwh)</td>
<td>100 Ah (3.84 kwh)</td>
<td>150Ah (5.76kwh)</td>
<td>200 Ah (7.68 kwh)</td>
</tr>
<tr>
<td height="27">Charge Voltage (V)</td>
<td>43.2</td>
<td>43.2</td>
<td>43.2</td>
<td>43.2</td>
</tr>
<tr>
<td height="27">EOD Voltage (V)</td>
<td>27.6</td>
<td>27.6</td>
<td>27.6</td>
<td>27.6</td>
</tr>
<tr>
<td height="27">Recommended Charge Current (A)</td>
<td>25</td>
<td>50</td>
<td>75</td>
<td>100</td>
</tr>
<tr>
<td height="27">Max. Charge Current (A)</td>
<td>50</td>
<td>80</td>
<td>120</td>
<td>150</td>
</tr>
<tr>
<td height="27">Continuous Discharge current (A)</td>
<td>60</td>
<td>120</td>
<td>180</td>
<td>240</td>
</tr>
<tr>
<td height="38">Dimensions (L*W*H)</td>
<td>16.5 * 6.5 * 7.3 inch<br />(418 *164 *185 mm)</td>
<td>16.5 * 6.5 * 7.3 inch *2 parallel<br />(418 *164 *185 mm) *2 parallel</td>
<td>16.5 * 6.5 * 7.3 inch *3 parallel<br />(418 *164 *185 mm) *3 parallel</td>
<td>16.5 * 6.5 * 7.3 inch *4 parallel<br />(418 *164 *185 mm) *4 parallel</td>
</tr>
<tr>
<td height="27">Weight</td>
<td>38.6 Ibs (17.5 kg)</td>
<td>77.2 Ibs (35.0 kg)</td>
<td>115.8 Ibs (42.5 kg )</td>
<td>144.4 Ibs (70.0 kg)</td>
</tr>
<tr>
<td height="27">IP Grade</td>
<td colspan="4">IP65</td>
</tr>
<tr>
<td height="27">Charge Operating Temperature</td>
<td colspan="4">0&deg;C~60&deg;C *</td>
</tr>
<tr>
<td height="27">Discharge Operating Temperature</td>
<td colspan="4">-20&deg;C~60&deg;C</td>
</tr>
<tr>
<td height="27">Communication</td>
<td colspan="4">CAN-Bus</td>
</tr>
<tr>
<td height="27">Parallel Function</td>
<td colspan="4">Can support max 8 pcs in parallel connection</td>
</tr>
<tr>
<td height="27">Cycle Life</td>
<td colspan="4">5000 cycles **</td>
</tr>
<tr>
<td height="27">Relative Humidity</td>
<td colspan="4">20%RH-80%RH (non-condensing)</td>
</tr>
<tr>
<td height="27">Charger</td>
<td colspan="4">Compatible with ACE chargers and approved chargers</td>
</tr>
</tbody>
</table>
</div>
<p>&nbsp;</p>
<div class="over-tabs">
<table style="border-collapse: collapse; border-color: #000000; border-style: solid;" border="1" cellspacing="0" cellpadding="0"><colgroup><col /><col /><col span="3" /></colgroup>
<tbody>
<tr class="firstRow" style="background-color: #005dbc;">
<td height="40"><strong><span style="color: #ffffff;">Model</span></strong></td>
<td><strong><span style="color: #ffffff;">Wire</span></strong></td>
<td><strong><span style="color: #ffffff;">Input Voltage(V)</span></strong></td>
<td><strong><span style="color: #ffffff;">Output Voltage(V)</span></strong></td>
<td><strong><span style="color: #ffffff;">Output Current(A)</span></strong></td>
</tr>
<tr>
<td height="27">FCM(VC)-2420</td>
<td>Single</td>
<td>110/220</td>
<td>29.2</td>
<td>20</td>
</tr>
<tr>
<td height="27">FCM(VC)-2440</td>
<td>Single</td>
<td>110/220</td>
<td>29.2</td>
<td>40</td>
</tr>
<tr>
<td height="27">FCM(VC)-3625</td>
<td>Single</td>
<td>110/220</td>
<td>43.2</td>
<td>25</td>
</tr>
<tr>
<td height="27">FCM(VC)-3650</td>
<td>Single</td>
<td>110/220</td>
<td>43.2</td>
<td>50</td>
</tr>
</tbody>
</table>
</div>
<p>&nbsp;</p>
<p>*with heating option -20℃~60℃</p>
<p>**vary with operating conditions</p>
